| Basic Info |
Brand: Canon; Model: EOS 70D; Release Date: July 2013; Imaging Processor: DIGIC 5+; Body Material: Magnesium alloy (top/bottom/front), Polycarbonate resin (rear); Continuous Shooting: 7.0 fps (max 31 JPEG / 15 RAW frames) |
| Sensor |
Type: APS-C CMOS (22.5 × 15.0 mm); Effective Pixels: 20.2 Megapixels; Total Pixels: 20.9 Megapixels; Aspect Ratio: 3:2; Low-Pass Filter: Built-in/Fixed; Sensor Cleaning: Automatic (Self Cleaning Sensor Unit), Manual cleaning, Dust Delete Data; Key Feature: Dual Pixel CMOS AF |
| Lens & Focus |
Lens Mount: EF/EF-S; Focal Length Multiplier: 1.6×; AF System (Viewfinder): 19 AF points (all cross-type, center dual cross-type at f/2.8); AF System (Live View/Video): Dual Pixel CMOS AF (80% frame coverage); AF Working Range: EV -0.5–18 (Viewfinder, 23°C, ISO 100); EV 0–18 (Live View, 23°C, ISO 100); Focus Modes: One-Shot, AI Servo, AI Focus, Manual (MF); Focus Area Selection: Manual, Automatic, Zone, Single Point |
| Exposure |
Shutter Speed: 1/8000–30 sec, Bulb; Flash Sync Speed: 1/250 sec; Exposure Compensation: ±5 EV (1/3 or 1/2 EV steps); ISO Sensitivity: Auto (100–6400), 100–12800 (expandable to 25600 as H1); Metering: 63-zone Evaluative, Center-weighted average, Spot (approx. 2.4% of viewfinder), Partial (approx. 6.5% of viewfinder) |
| Image Quality |
File Formats: Still – JPEG (Exif 2.3), RAW (14-bit CR2), RAW+JPEG; White Balance: Auto, Daylight, Shade, Cloudy, Tungsten, White Fluorescent, Flash, Custom (2 presets), Color Temperature Setting; Aspect Ratios: 3:2 (native), 16:9, 4:3, 1:1; Creative Filters: Grainy B/W, Soft Focus, Fish-eye Effect, Toy Camera Effect, Miniature Effect, HDR Art, Watercolor, Oil Painting |
| Still Image Sizes |
L (20M): 5472×3648; M (8.9M): 3648×2432; S1 (4.5M): 2736×1824; S2 (2.5M): 1920×1280; S3 (0.3M): 720×480; RAW: 5472×3648 |
| Video Recording |
Resolutions & Frame Rates: 1920×1080 (60/50/30/25/24 fps), 1280×720 (60/50/30/25 fps), 640×480 (30/25 fps); Key Feature: Dual Pixel CMOS AF for continuous autofocus; Format: H.264 (MPEG-4 AVC) in MOV; Audio: Stereo mic (built-in), External mic input (3.5mm jack), Headphone jack (3.5mm jack) |
| Display & Viewfinder |
LCD: 3.0" TFT (Clear View II, vari-angle, capacitive touchscreen, 1,040,000 dots); Viewfinder: Optical (pentaprism, 100% coverage, 1.00× magnification, -3.0–+1.0 diopter adjustment) |
| Storage |
Media: Dual SD/SDHC/SDXC slots (UHS-I compatible) |
| Power |
Battery: Rechargeable Li-ion LP-E6 (1800 mAh); CIPA Battery Life: ~920 shots (viewfinder), ~350 shots (live view) |
| Connectivity |
Hi-Speed USB 2.0, HDMI Mini C (CEC, Type A), AV Out (NTSC/PAL); Wi-Fi: Built-in (IEEE 802.11 b/g/n); No NFC/Bluetooth; Direct Print: PictBridge |
| Dimensions & Weight |
Dimensions: 139.0 × 104.3 × 78.5 mm (5.47 × 4.11 × 3.09 in); Weight: ~755 g (26.63 oz) with battery & card, ~675 g (23.81 oz) body only |
