| Brand |
Samsung |
| Model |
WB1000 (also known as TL320 in North America) |
| Release Date |
Announced August 2009 |
| Camera Type |
Premium Ultra-Compact Digital Camera (Full Manual Control Supported) |
| Sensor Type |
1/2.33-inch CCD Sensor |
| Effective Pixels |
Approx. 12.2 Megapixels |
| Total Pixels |
Approx. 12.4 Megapixels |
| Max Image Resolution |
4000 x 3000 Pixels |
| Image Format |
JPEG (Exif 2.21, DCF, DPOF 1.1, PictBridge 1.0) |
| Image Aspect Ratio |
4:3, 3:2, 16:9 |
| Lens |
Schneider-Kreuznach 5x Optical Zoom Lens
Actual Focal Length: 4.6–23.0 mm (35 mm equivalent: 24–120 mm) |
| Aperture Range |
F2.8 (Wide) – F5.8 (Tele) |
| Optical Zoom |
5x |
| Digital Zoom |
Up to 5x (Total: 25x with Optical + Digital) |
| Focus System |
TTL Contrast Detect Auto Focus (Multi AF, Center AF, Selection AF, Tracking AF, Face Detection AF, Manual Focus) |
| Focus Range |
Normal (Wide): 40 cm – Infinity
Normal (Tele): 80 cm – Infinity
Macro (Wide): 5 cm – Infinity |
| ISO Sensitivity |
Auto, 80, 100, 200, 400, 800, 1600, 3200 (3200 only at 3MP) |
| Shutter Speed |
Auto: 1/8 – 1/2000 sec
Program: 1 – 1/2000 sec
Manual: 16 – 1/2000 sec
Night Scene: 8 – 1/2000 sec
Fireworks: 2 sec |
| Exposure Control |
±2 EV Exposure Compensation (1/3 EV steps), Multi-segment, Centre-weighted, Spot, Face Detection Metering |
| Image Stabilization |
Optical Image Stabilization (OIS) |
| Main Display |
3.0-inch TFT LCD (hVGA), 460,800 Pixels (Non-Touch, High Brightness) |
| Video Recording |
1280×720 (30/15fps, 720p HD), 640×480 (30/15fps), 320×240 (60/30/15fps)
H.264 (MP4) Format, Stereo Audio, Built-in Stereo Microphone & Mono Speaker |
| Storage |
Internal Memory: 76 MB
External Card: SD / SDHC / MMC / MMCplus (up to 32GB supported) |
| Power Supply |
Rechargeable Lithium-ion Battery SLB-11A (3.7V, 1130 mAh), USB/AC Charging Supported |
| Flash Modes |
Auto, Auto & Red-eye Reduction, Fill-in, Slow Sync, Flash Off, Red-eye Fix |
| Flash Range |
Wide: 0.3 – 4.0 m; Tele: 0.5 – 2.5 m (ISO Auto) |
| White Balance |
Auto, Daylight, Cloudy, Fluorescent (H/L), Tungsten, Custom |
| Self-timer |
2 seconds, 10 seconds, Double, Motion Timer |
| Continuous Shooting |
Single Shot, Continuous Shot (Up to 3fps), AEB (Auto Exposure Bracketing) |
| Scene Modes |
Smart Auto, Program, Manual, Aperture Priority, Shutter Priority, Portrait, Landscape, Night, Night Portrait, Close-up, Macro, Beach, Snow, Sunset, Fireworks, Party, Indoor, Backlight, Text, Children, Food, Dawn/Dusk, Beauty Shot |
| Additional Features |
Face Detection (Up to 10 Faces), Smile Capture, Blink Detection, In-camera Red-eye Fix, Voice Memo, Date Imprinting, Smart Filter (B&W, Sepia, Negative, Vivid, Soft Focus), In-camera Editing (Resize, Rotate, Trim), Recycle Bin, Frame Guide, Photo Help Guide, HDMI Anynet+ (CEC) |
| Dimensions (W x H x D) |
97.0 x 61.0 x 21.0 mm (excluding protrusions) |
| Weight |
Approx. 160 g (body only, without battery & memory card)
Approx. 190 g (with battery & memory card) |
| Connectivity |
USB 2.0 High Speed, HDMI (Type D) Output, NTSC/PAL Video/Audio Output, DC-in Jack, PictBridge |
| Body Colors |
Black (Stainless Steel Body) |
